Coatings Testing Term of the Month: Weight per Gallon

What is Weight per Gallon?

coatingsWeight per gallon is a measurement of the density of a product or coating. It's important for batch-to-batch consistency and accuracy purposes. This measurement is part of the quality control process that ensures the final product has the correct amount of each material required in the coating formulation. Weight per gallon helps confirm customers consistently get the same, high-quality coatings and that those coatings perform as expected.

How is it Measured?

Weight per gallon is determined using weight per gallon cups, which are standardized using the specific gravity of water (density of 8.32 pounds per gallon at 77°F). They are made out of stainless steel so that both water based and solvent based products can be tested and the cups can easily be cleaned without damage. Care must be taken not to leave material in the cup for long periods of time because of potential reaction that could occur in the cup.

To determine the weight per gallon of a product, follow these four quick steps:

  1. Place the cup and lid on a laboratory scale and the scale is tared to zero
  2. Add product to the cup and then place the lid on top (the lid has a small hole in it that allows excess material out)
  3. Wipe the excess material from the lid
  4. Record the weight of the filled cup

Why is it Measured?

Liquid formulations contain raw materials that are supplied with a given weight per gallon. Their weight per gallon is also calculated against the specific gravity of water. If we add up all the raw materials weights and volumes for a specific formula and divide the total weight by the total volume, we can determine the theoretical weight per gallon of the product.

Most products are allowed variance 0.2 pounds per gallon which allows for variability in manufacturing but yields the same quality of product. If the weight per gallon is out of the 0.2 pounds per gallon specification, this allows for natural fluctuations in the manufacturing process. Other tests can then be utilized to further determine which material has varied from the given recipe and adjustments can be made to bring the product back into specification.

In the end, this test reflects the quality control process. Other items tested during this process in the lab, besides weight per gallon, include pH level, viscosity, etc.

The Daily Responsibilities of Technical Directors and Operations Managers

We know that your performance at work is defined through many objectives, including:

  • Failure rate
  • Complaints
  • Rework
  • Units of output
  • Production downtime
  • How well you are producing
  • The number of products that can run through the assembly line per hour

In simple terms, we conduct quality checks in the lab, like weight per gallon, to ensure that our customers receive the same high quality of finished goods each time. Any coatings manufacturer would go through this process for every batch; it’s industry standard. Think about it: if you were to take a product that was out of specification for weight per gallon and apply it by roller, brush, or spray, you wouldn’t get the same finished film thickness. This could potentially affect your product’s performance and or add additional costs to the customer.

Quality checks make certain our customers that they will receive high quality industrial coatings and each batch will be the same.



Aexcel Coatings



As a manufacturer, why do quality control checks make a difference for your products? Share your experiences with us in the comments below!
